CAFS5025 Diameter 25 Interface 1’’ L 136 H 72 W 51 d 25 Interface NTP 1 inch

Product Description

The CAFS5025 Gas Mass Flow Sensor, utilizing microelectromechanical system (MEMS) flow sensor chip technology, is designed for the measurement and process control of clean and relatively dry gas flows across various applications. Its unique packaging technology enables it to meet different flow measurement ranges, ensuring high sensitivity, reliability, stability, and low cost. The CAFS5025 integrates a MEMS flow sensing unit with high-precision digital processing and calibration circuits (MCU). The built-in Δ-Σ A/D converter and internal calibration logic circuit, combined with the MCU processor, ensure real-time and accurate flow signal acquisition and internal compensation algorithm processing. This design eliminates the need for external calibration and compensation, guaranteeing high-precision flow outputs. The sensor offers user-friendly digital output communication, allowing easy access to data.

Product Features:

• High Accuracy: 1.5% F.S accuracy ensures precise measurements.
• Linear Output: No need for temperature compensation.
• Long-Term Stability: Minimal zero-drift over time.
• Quick Response: Fast response time of 65 ms.
• Wide Flow Range: Measures flow rates from 0-60 m/s and withstands impacts of up to 100g.
• Durable Core: Solid-state sensing core with no surface cavities or fragile films, providing resistance to blockage and pressure impacts.
• Versatile Outputs: Analog output (1-5 V) and optional digital RS485 communication output.
• Humidity Adaptability: Suitable for relatively humid gas measurements.
• Environmental Tolerance: Operating temperature range of -25°C to 85°C, storage temperature range of -40°C to 90°C, and humidity tolerance of 0 to 100% RH.
• Condensate Resistance: Sensor is resistant to condensate water.

Performance Specifications:

Product Model Specifications:

Applications:

• Industrial: Enhancing process control and automation.
• Medical: Used in oxygen generators, CPAP equipment, and respiratory devices.
• Petroleum: Monitoring and controlling gas flows in refining and processing.
• Instrumentation: Providing precise flow measurements in various instruments.
• Gas: Ensuring accurate gas flow measurements in distribution and usage.
• Chemical: Controlling and monitoring gas flows in chemical processes.
• Smelting: Managing gas flows in metallurgical processes.
• Food Processing: Ensuring proper gas flows in food production.
• Electromechanical Equipment: Integrating into various mechanical systems for accurate gas flow measurement.

The CAFS5025 Gas Mass Flow Sensor is a versatile, high-precision solution for a wide range of gas measurement applications, promoting efficiency and accuracy across various industries.
