Brand Name : | Consensic |
Model Number : | CAFS1000B |
Price : | Offline conversation or face-to-face discussion |
Payment Terms : | L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments |
Delivery Time : | 3-7 work days |
Certification : | |
Supply Ability : | 999 |
Consensic, Inc. is an emerging MEMS design, manufacturing and
manufacturing U.S.-owned enterprise with a management team with
rich experience in sensors and semiconductors. Our commitment to
innovative and market-competitive sensor manufacturing provides
more options for micro-miniature packaging for advanced integrated
systems. By continuing to break off.Technological innovation to
provide customers with more MEMS products with market
competitiveness.
Wuxi Consensic Electronic Technology Co., Ltd. has the core
competence in MEMS design, manufacturing and testing, and can
provide customers with high-precision and high-reliability MEMS
products and solutions. From silicon to tested design quality and
reliability, we strive to exceed our customers' requirements. At
the beginning of the company's establishment,We work closely with
our customers and non-collaborators, and at the same time create
success together with the concept of hand-in-hand win-win.
Functional items | 10-800 KG / H 14V DC IP40 Medical Flow Sensors 101.325kPa Air Calibration Method | ||
Performance parameters | unit | remark | |
Flow range | 10-800 | Kg/h | Customizable |
Supply voltage | 14 | VDC | |
precision | ±2.0 | % FS | |
repeatability | <0.5 | % | |
Response time | 20 | ms | Optional |
Maximum pressure | 0.3 | MPa |
Output mode | Frequency output 2.05~11.69 Analog outputs 1-5 | KHz V | Optional |
temperature | -40~125 | ℃ | |
Ingress protection | IP40 | ||
Calibration method | Air, 20°C, 101.325kPa | ||
Overall material | ABS |
![]() |
