Absolute Pressure Sensor CPS175 Low Power Consumption External Clock Not Required High Resistance To Sensing Media

Ask Lasest Price
Brand Name :	Consensic
Model Number :	CPS175

Add to Cart

Product Details
Company Profile

Absolute Pressure Sensor CPS175 Low Power Consumption External Clock Not Required High Resistance To Sensing Media

Absolute Pressure Sensor CPS175 Low Power Consumption External Clock Not Required High Resistance To Sensing Media

The CPS175 is a resistive absolute pressure sensor solution with a

fully calibrated pressure compensated analog output for low

pressure applications, such as MAP (Manifold Absolute Pressure)

systems.

The CPS175 solution comprises of an ultra-small resistive MEMS

pressure sensor and a conditioning ASIC for accurate pressure

measurements in factory calibrated ranges for the MAP

applications. An integrated sigma-delta based ADC combined with

internal calibration logic provides a high level analog output signal

that is proportional to the applied pressure.

Absolute Pressure Sensor CPS175 Low Power Consumption External Clock Not Required High Resistance To Sensing Media
